When it comes to high-performance micro-displays, the 1.03-inch Micro-OLED  sets an impressive standard. With a resolution of 2560x2560 pixels, brightness levels reaching 3000 nits, and seamless integration through a MIPI interface, this compact display is designed to deliver exceptional clarity and performance. Built for applications such as viewfinders and head-mounted displays, this Micro-OLED is more than just a screen—it’s a powerhouse in a small package.

Unrivaled Resolution: A 2560x2560 Pixel Masterpiece

The SY103WAM13-00 boasts a real RGB resolution of 2560x2560, packing 19.66 million subpixels into its 1.03-inch diagonal frame. This ultra-high pixel density ensures every detail is rendered with exceptional precision, making it ideal for professional-grade imaging applications. Whether used in AR/VR devices or medical tools, the display’s sharpness transforms user interactions into immersive experiences.

The innovative RGB π pixel arrangement optimizes color accuracy and viewing consistency across the display. Coupled with scaling options like 1.33x (1920x1920 to 2560x2560) and 2x (1280x1280 to 2560x2560), this display supports a variety of input resolutions while maintaining flawless visuals.

Bright and Vivid: 3000 Nits for Any Environment

One of the standout features of this Micro-OLED is its 3000 nits peak brightness, making it one of the brightest displays in its class. This level of luminance ensures exceptional visibility even in high ambient light conditions, making it indispensable for outdoor or industrial applications. The display’s 500,000:1 contrast ratio further enhances image depth and vibrancy, ensuring that colors pop and blacks appear truly deep.

With support for a 90% DCI-P3 color gamut, the display achieves professional-grade color accuracy, delivering stunning and lifelike visuals across a wide range of applications.

Compact Power: 1.03 Inches of Performance

Despite its compact size—just 18.432mm x 18.432mm in active area—this display is designed for high functionality. Weighing only 2 grams, it integrates seamlessly into portable devices while delivering superior performance. Its 7.2μm pixel size ensures crisp image rendering, making it ideal for use in space-constrained designs.

The display operates efficiently at a power consumption of 2400mW, even under demanding conditions like 100% duty emission and 3000 nits brightness. This balance of power and performance allows for extended device operation without compromising visual quality.

MIPI Interface: Seamless Integration for Modern Applications

The SY103WAM13-00 supports a robust MIPI DSI v1.01 interface with one or two-port configurations, providing data transfer rates of up to 1.0Gbps per lane. This ensures a seamless connection with a wide range of devices, from head-mounted displays to advanced imaging systems. The inclusion of VESA DSC compression allows for efficient data transmission, further optimizing performance without sacrificing image quality.

Built for Versatility and Precision

The Micro-OLED display includes features such as scan direction selection and orbit support, which reduce burn-in and extend display life. It also incorporates temperature compensation, ensuring consistent performance across operating temperatures ranging from -20°C to 70°C. These capabilities make it well-suited for professional environments where reliability and precision are critical.

Applications Across Industries

1. AR/VR Devices: The high resolution and brightness enhance immersive experiences, providing users with lifelike visuals and smooth performance.
2. Medical Imaging: The compact design and precise rendering make it invaluable for diagnostic tools requiring detailed visuals.
3. Industrial Displays: The durability and brightness allow it to perform exceptionally in harsh environments.
4. Professional Viewfinders: Photographers and videographers can rely on its clarity for perfect framing and shot composition.

The 1.03-inch Micro-OLED display is a testament to how advanced technology can redefine user experiences. With its unparalleled resolution, exceptional brightness, and efficient design, this display is not just a component—it’s a cornerstone for next-generation devices.
