n the world of cutting-edge display technologies, the 0.49-inch Micro-OLED stands as a remarkable feat of engineering. Designed for devices where space is limited but performance cannot be compromised, this Micro-OLED offers a 1920x1080 Full HD resolution and an unparalleled 3000 nits peak brightness. Compact yet powerful, it redefines what’s possible in micro-displays.

A Revolution in Compact Displays

At just 0.49 inches diagonally, this Micro-OLED delivers a resolution that rivals much larger screens. Its 5.616μm x 5.616μm pixel size ensures crystal-clear images, making it ideal for applications like AR glasses, head-mounted displays, and professional-grade viewfinders. This compact module integrates both panel and logic drivers on a single-crystal silicon base, which not only enhances performance but also reduces power consumption and weight.

Stunning 1080p Resolution in a Tiny Frame

Despite its diminutive size, the display supports a 1920x1080 resolution, offering over 2 million pixels in its tiny 10.783mm x 6.065mm active area. This ensures fine details and razor-sharp visuals, whether you’re navigating immersive AR environments or capturing moments through a camera viewfinder. The display also supports multi-resolution scaling, seamlessly adapting input resolutions like 960x540 or 1440x810 to its native FHD output.

3000 Nits Brightness: Exceptional Visibility Anywhere

What truly sets this display apart is its 3000 nits peak brightness, a level typically reserved for much larger displays. This feature guarantees outstanding visibility, even in bright outdoor conditions. Coupled with a contrast ratio of 50,000:1, it produces vivid colors and deep blacks, delivering a dynamic viewing experience ideal for professional applications and demanding environments.

The display also supports DCI-P3 color gamut coverage up to 95%, ensuring lifelike color reproduction with a gamma value of 2.2 for consistent image quality.

Seamless Performance with MIPI Interface

The SY049LDM01 features a robust MIPI DSI v1.01 interface, providing efficient data transmission with 1.0 Gbps per lane through four lanes. This ensures compatibility with modern systems while reducing latency, critical for real-time applications like AR and VR. The built-in VESA DSC compression further enhances performance, enabling the display to handle high-resolution input efficiently.

Advanced Features for Professional Applications

1. Frame Rates Up to 90Hz: The display supports refresh rates of up to 90Hz, ensuring smooth visuals for fast-paced content.
2. Wide Brightness Adjustment: Offers flexibility for diverse lighting conditions, from dim indoor settings to bright outdoor environments.
3. Temperature Compensation: Ensures reliable performance across a wide operating range of -20°C to 70°C.
4. Orbit Technology: Reduces image retention, extending the display’s lifespan.
5. Scan Direction Selection: Customizable display orientation for versatile use cases.

Efficiency Meets Performance

The display achieves its exceptional performance while maintaining low power consumption. Operating at 480mW under typical conditions (90Hz refresh rate, 1800 nits brightness), it strikes a balance between efficiency and capability. Weighing approximately 1 gram, it integrates seamlessly into lightweight and portable devices without compromising on quality.

Applications Across Industries

This display is perfectly suited for a wide array of applications:

• Augmented Reality (AR): Enables immersive experiences with sharp visuals and high brightness, ensuring clarity in any environment.

• Professional Viewfinders: Provides photographers and videographers with real-time, high-resolution previews for precise framing and composition.

• Head-Mounted Displays (HMDs): Powers advanced VR systems with its combination of compact size, high resolution, and vibrant visuals.

• Industrial and Medical Displays: Ideal for precision tools that require high brightness and accurate color reproduction.

A New Era in Micro-Displays

The 0.49-inch Micro-OLED redefines the limits of what a compact display can achieve. Its combination of 1080p Full HD resolution, 3000 nits brightness, and seamless integration through advanced interfaces makes it a cornerstone for next-generation devices. Whether it’s enhancing AR experiences, powering professional-grade tools, or enabling innovative portable devices, this display sets a new benchmark for performance in the smallest of packages.
