Display Specifications
- Resolution : 128 x 64 pixel
- Display Mode : Passive Matrix OLED
- Display Color : Monochrome
- Module Dimension : 35.4 x 33.5 x 2.7 mm
- Viewing Area : 29.42 x 14.7 mm
- Power Supply : 2.8 V
- Interface : I2C
- Controller IC : SH1106
- Operation Temperature : -40℃~85℃
- Storage Temperature : -40℃~85℃
Dimension
Resources
Driver IC: SH1106-V2.6
Arduino SH1106 is compatible SSD1306, You can refer Library: u8g2 .Uncomment device U8G2_SSD1306_128X64_NONAME_1_SW_I2C u8g2(U8G2_R0, /* clock=*/ 13, /* data=*/ 11, /* reset=*/ 8);
Because the SSH1106 RAM is 132*64 pager-buffer and SSD1306 is 128*64, So there is display problem if you use SSD1306 dirver. You'd better modify the start address from 0x02
