Display Specifications
- Diagonal Dimension : 1.28 inch
- Resolution : 240RGB x 240 pixel
- View Direction : All
- Touch Mode : None
- Module Dimension : 36.01(H) x 34.74(V) x 1.66(T) mm
- Viewing Area :32.4 x 32.4 mm
- Supply Voltage : 2.8 V
- Interface : SPI
- Luminance : 350 cd/m2
- Drive IC : GC9A01
- Operation Temperature: -20°C~ +70°C
- Storage Temperature : -30°C~ +80°C
Dimensions
Resources
- Datasheet: DM-TFTR128-466、GC9A01
- Example code : GC9A01-SPI-240 x 240
- 3D : DM-TFTR128-466
