Display Specifications
- Resolution : 128 x 64 pixels
- Display Mode : FSTN Positive, Transflective
- View Direction : 6:00
- Module Dimension : 89.0 x 70.0 x 13.6(MAX) mm
- Power Supply : 5.0 V
- Backlight : White LED
- Interface : PARALLEL MPU Interface
- Controller IC : RA6963
- Operation Temperature : -20℃~70℃
- Storage Temperature : -30℃~80℃
- Weight : 77.1 g
Dimensions
Resources
- DM-LCD12864-460
- Display Driver IC: RA6963-V1.3
