Display Specifications
- Diagonal Dimension : 2.4 inch
- Resolution : about 240 x 320 pixel
- View Direction : 12 o’clock
- Touch Mode : Resistive
- Module Dimension : about 43.00 x 70.26 x 3.75 mm
- Viewing Area : about 36.72 x 48.96 mm
- Supply Voltage : 2.8 V
- Interface : 4 wire SPI
- Luminance : - cd/m2
- Drive IC : ILI9341,XPT2046
- Operation Temperature : -20℃~70℃
- Storage Temperature : -30℃~80℃
Dimensions
Resources
- DM-TFT24-363
- Display Controller: ILI9341-V1.05
- TP Driver IC: XPT2046
