Display Specifications
- Diagonal Dimension : 2.0 inch
- Resolution : 320(RGB) x 240 pixel
- View Direction : Wide angle
- Touch Mode : None
- Module Dimension : 46.5 x 41.56 x 2.7 mm
- Viewing Area : 40.80(H)*30.60(V) mm
- Supply Voltage : 3.3 V
- Interface : 8/9/16/18Bit MCU,3/4SPI+16/18Bit RGB Interface,3-line/4-line Serial
- Luminance : 350 cd/m2
- Drive IC : ILI9342C
- Operation Temperature : -20℃~70℃
- Storage Temperature : -30℃~80℃
Dimensions
Resources
