Display Specifications
- Diagonal Dimension : 3.0 inch
- Resolution : 480 x RGB x 480 pixel
- View Direction : -
- Touch Mode : None
- Module Dimension : 58.01 × 61.38 × 2.45 mm
- Viewing Area : 53.28 x 53.28 mm
- Supply Voltage : 1.8/2.8 V
- Interface : RGB 24bit+SPI
- Luminance : 450 cd/m2
- Drive IC : HX8369A
- Operation Temperature : -20℃~70℃
- Storage Temperature : -30℃~80℃
Dimensions
Resources
- Datasheet : DM-TFTR30-455、HX8369A
- Example code : HX8369A-SPI-480x480
- 3D : DM-TFTR30-455
- Video : DM-TFTR30-455
